AUTOMATIC THREAD TRIMMER

The Juki mid-arm quilting machine is equipped with an automatic thread trimmer device that simultaneously trims the needle and bobbin threads at the sewing end. All it takes is a gentle push on the push-button. It uses the thread trimming mechanism.

Easy Bobbin Replacement

A new bobbin case latch and an enlarged bobbin case area make it easier to remove and replace the bobbin.

PREDETERMINED NEEDLE STOP POSITION

When you stop sewing, the Juki TL-15 comes to an accurate stop with the needle down. To move the needle up or down as desired, simply press the needle up/down button.

Heavy-Weight Materials are Sewn with Ease

The speed control mechanism, operated by microcomputer, allows the Juki TL-15 machine to sew materials at low speeds. This provides for accurate feed and perfect stitching when sewing heavy weight fabrics, quilting and multiple layers of materials.

Automatic Needle Threader

The push lever automatic needle threader easily threads the needle without eyestrain and allows you to start sewing quickly.

Adjustment of Presser Foot Pressure

Presser foot pressure can be adjusted according to the fabric being sewn by turning a regulator located on the top of the machine. The pressure amount can then be viewed at a pressure indicator.

Two Types of Quilting Foot / Drop Feed

The quilting feet are designed for free motion quilting and free-hand embroidery. Two types of quilting feet are supplied as standard accessories with the machine. A 1/5" quilting foot is used for basic quilting and the 1/4" quilting foot for precision sewing with 1/4" stitch width. The feed dog can be raised and lowered simply by depressing a switch. When quilting, the drop feed allows you to sew curved stitches with ease.

Knee Lifter Lever

The knee lifter allows you to lift/lower the presser foot without using your hands. The presser foot can be raised as high as 12mm, so that light to heavyweight materials is easily handled in and out of the sewing area with ease.

Thread Tension Scale

The machine is provided with the thread tension scale, which allows you to adjust the tension according to the thread and material to be used.

Industrial Machine Engineering

The arm and bed of the Juki TL-15 are constructed of aluminum die-casting. This touch body lowers vibration while sewing and ensures high-quality stitching. Since the Juki TL-15 has many industrial sewing machine features, it is possible to attach several types of industrial presser feet.

• Foot Controller with Thread Trimming Function
• Subtension Unit built in for freemotion tension control
• Maximum Sewing Speed Control
• Predetermined Stop Position of the Needle
• Automatic Thread Trimmer
• Heavyweight Materials Sewn with Ease
• Automatic Needle Threader
• Thread Tension Scale
• Easy Bobbin Replacement
• Adjustment of Presser Foot Pressure
• Updated with LED lights
• Throat space is 9" from the needle to the right and 6 3/4" top to bottom
• One pedal operation
• Up to 1500 spm
• Aluminum die cast arm and bed
• Extension table
• Light weight and portable
• Supplied with HA type needles.
• Longer arm and sewing bed
• Basic sewing functions operated by foot pedal
• Automatic bobbin winder
• Small screwdriver
• T screwdriver
• Lint brush
• Bobbins
• Spool cap
• Oiler
• Needle pack
• Straight stitch foot
• Power cord
• Instruction manual
• Knee lever
• Dimensions: 17.8 x 8.6 x 13.8 Inches
• Stitch length: Max. 6mm
• Lift of the presser foot: By Lever, Max. 9mm; By Knee Lifter, Max. 12mm
• Needle: HAx1 (130/705H) #7-#18 (HLx5#9-#16)
• Weight(Machine only): 11.5kg
• Rated Voltage/Power consumption: 120V/1.4A, 100W
• Power consumption of the lamp: 12V, 3W
• Auxiliary table (Dimensions): 590 x 277 (mm)
• Horizontal axis full rotary hook
• Throat area: 8.5 inches long x 5.9 inches tall
• Auxiliary table: 12 inches wide x 23 inches long
