Product Description

Hotronix Stampinator 480 Screen Printing Press

Ready to revolutionize your automatic screen printing production lines, maximize hourly throughput, and achieve a flawless, retail-ready finish on every garment? The Stahls' Hotronix Stampinator 480 Heat Press is a groundbreaking, heavy-duty automatic heating solution engineered to mount directly into your automatic screen printing press. By installing seamlessly into a print head station, this commercial powerhouse automates structural workflows that used to require taking garments off the press for separate manual handling.

The defining advantage of the Stampinator 480 is its incredible versatility in-line. It completely replaces standard, energy-hungry flash cure units by combining high-density radiant heat with targeted pneumatic pressure right on the platen. This makes it an absolute game-changer for matting down shirt fibers, heat-curing underbases, flash drying plastisol inks, stamping down Direct-to-Film (DTF) transfers in-line, and applying foil or rhinestones. Available in both 120V and 240V configurations, this high-durability system applies uniform, edge-to-edge heat and pressure to ensure optimal ink curing and ultra-smooth fabric preparation without creating a manual bottleneck.

Features

In-Line Automatic Integration: Mounts directly into an automatic screen printing press head to eliminate off-press manual heat pressing.
Fiber Matting Capability: Applies heat and pneumatic pressure to lay down loose shirt fibers before or during printing, producing smooth, bright prints.
Multi-Function In-Line Processing: Cures underbases, flash-dries plastisol, stamps DTF transfers, and applies foil or rhinestones on the carousel.
Dual Voltage Options: Available in 120V and 240V configurations to match your facility's electrical infrastructure.
Pneumatic Pressure System: Delivers consistent, repeatable downward force across the entire platen surface.
Energy-Efficient Alternative: Replaces traditional flash cure units while consuming less energy and providing superior finish quality.

Specifications

Stampinator® 480
Actual Dimensions: 21" x 31.13" x 8" (53 x 79 x 20 cm)
Actual Weight: 70 lbs (32 kg)
Heater: 16” x 20” (40 x 50 cm)

Universal Features

Made in the USA
- Compatible with most commercially available automatic press brands including:
- ROQ
- M&R
- Workhorse
- Tas
- Anatol
- MHM
- Certified by SGS to UL standards
- CE/RoHS approved
- 120 v; 15 amps; 1800 w
- 240 v; 7.5 amps; 1800 w
